12T Roadheader
Overview
About this machine
The 12T Roadheader is a 12-ton crawler machine for underground excavation. Compare length, cutting-head power and cross-section in the table below, then contact GTA50 if you need a project-specific setup.
Specifications
Key data
Working Weight
12,000 KG
Length
6.50 meters
Cutting Head Electric Motor
75 kW
Cross Section Area
3.50 X 3.50 meters
Technical Table
Full specification
| Property | Value |
|---|---|
| Working Weight | 12,000 KG |
| Length | 6.50 meters |
| Width | 1.85 meters |
| Height | 1.80 meters |
| Crawler Working Weight | 12 tons |
| Hydraulic System | Variable Displacement Load Sensing Pump |
| Cutting Head Electric Motor | 75 kW |
| Hydraulic System Electric Motor | 75 kW |
| Control Joysticks | Joystick and Manual |
| Cross Section Area | 3.50 X 3.50 meters |
3D Gallery
Multi-angle view
1 / 8
Videos
Field videos
12T Roadheader
Move forward with this machine
Let’s define the right configuration together.
